Product Description
Product Overview
The Mindway long working time thermal battery is engineered for mission-critical applications requiring high power density and extended activation life. Unlike conventional rechargeable batteries, our thermal battery remains inert until activated, providing reliable, one-shot power for missiles, launch vehicles, emergency systems, and downhole tools. With customizable activation time and working duration, this long working time thermal battery delivers consistent performance under extreme temperatures and harsh environments. delivering 5800s (≈97 minutes) of continuous power with stable 28V/12A output. It uses advanced electrolyte and thermal insulation technologies to maximize operational life.
Core Advantages of Our Extended Discharge Thermal Battery
Ultra-Long Operation Time: 5800s continuous discharge for long-range missions.
Stable High Power Output: 28V/12A consistent performance under dynamic loads.
Advanced Electrolyte System: Optimized molten salt electrolyte for extended runtime.
Efficient Thermal Insulation: Minimizes heat loss and maintains stable internal temperature
| Feature | Long Working Time Thermal Battery |
| Storage life | 10+ years (inert) |
| Activation time | 60milliseconds-2 seconds |
| Working duration | Extended (30s – 60+ min) |
| Operating Temp: | -50°C to +400°C (operating) |
| Safety during storage | Fully inert, no hazard |
| Rechargeable | No (one-shot high power) |
Typical Application for Long Working Time Thermal Battery
Long-range Missile /cruise missiles guidance and fuzing systems
Torpedo propulsion and guidance
Underwater endurance systems
Backup power for critical defense systems
Key technical indicators
Working hours: 5800s
Operating Voltage: 28 V
Working current: 12A
Customization Options for Long Working Time Thermal Battery
Operating Voltage: 750 V (Unit cell: 1.9 V – 2.1 V)
Unit Cell Current Output: 10 mA – 360 A
Combined Battery Current Output: 500 A
Power Density: 15 kW/kg
Energy Density: 120 Wh/kg
Activation Time: 60 ms – 2 s
Operating Duration: 5,000 s
Storage Life: 27 years
Operating Temperature Range: –55°C to +400°C
Activation Methods: Electric ignition, mechanical ignition (overload activation)
Diameter: Ø 13 mm – Ø 140 mm
Height: 20 mm – 500 mm
Note: This represents typical performance, not maximum capability
Mindway provides customized thermal battery solutions optimized for specific voltage profiles and mechanical constraints. Contact our engineering team for technical consultation.
Thermal battery principle
A thermal battery is a single-use, thermally activated reserve battery that employs electrical signals, mechanical force, or overload activation to ignite its internal heating system. This process melts the solid molten salt electrolyte between the cathode and anode into a conductive ionic state, thereby enabling the battery to deliver electrical power.
